Enerpac PAM1042 Air Hydraulic Pump
SGD6,924.14
SKU
ENP-PAM-1042
EnerpacPAM1042, Air Hydraulic Pump, 4/3 Manual Valve, 7,6 litres Usable Oil, For use with Double-Acting Cylinders.Reliable quality for your needs. Buy now!!
Model : PAM1042
- Twin air motor configuration delivers high-flow performance in first stage, up to 14 bar, for rapid cylinder advance
- 8 liter reservoir for use with a wide range of cylinders
- Integral shroud protects air motors and provides easy portability
| Maximum Operating Pressure | 10000 PSI |
|---|---|
| Cylinder compatibility | Double-Acting |
| Reservoir capacity | 462 in³ |
| Usable oil capacity | 7.6 ltr |
| Maximum flow at rated pressure | 9 in3/min |
| Output flow rate (in³/min) 1st Stage | 650 |
| Output flow rate (in³/min) 2nd Stage | 9 |
| Air consumption (scfm) | 18 |
| Air pressure range (psi) | 60 - 120 |
| Sound level (dBa) | 87 |
| Valve function | Advance / Hold / Retract |
| Valve model | VM43 |
| Valve operation | Manual |
| Valve type | 4-way, 3-position |
| Power source | Air |
| Product description | Model : PAM1042
|
| Weight (kg) | 30.300000 |
